59
ENGLISH
INSTALLATION & MAINTENANCE MANUAL • X-MIND AC • V2 • (06) • 08/2016 • NXACEN020B
REF
SPARE PARTS PANTOGRAPH TYPE ARM
x-mind ac®
CODE
(RAL 9010 color)
OLD COLOR Q.TY PCS
1 AC XG B (1) CABLE + 3 POLES CONNECTOR 39700384 1
2 DC XG B (2) CABLE + 5 POLES CONNECTOR 39700381 1
3 AC/DC XG B (3) COVER SET TUBEHEAD SIDE 29700990.C 29700990 9
4
PANTOGRAPH ARM ANTERIOR TIE-BEAM
(2 pz)
29700460 4
5
PANTOGRAPH ARM ANTERIOR TIE-BEAM
HOLDER
29700458 6
6 AC/DC XG B (6) PLASTIC SCREW CAP SET 29700991.C 29700991 7
7 AC/DC XG B (7) EXTENAL COVER 27500757.C 27500757 1
8 AC/DC XG B (8) INTERNAL COVER 27500758.C 27500758 1
9 AC/DC XG B (9) ELBOW COVER 29700993.C 29700993 8
10
PANTOGRAPH ARM ALLEN WRENCH
LOADING KEY
22000543 1
11 AC/DC XG B (11) INTERNAL COVER 27500758.C 27500758 1
12 AC/DC B (12) ESTERNAL COVER 27500757.C 27500757 1
13
PANTOGRAPH ARM POSTERIOR TIE-BEAM
(2 pz)
29700992 7
14 AC/DC XG B & HALF-MOON LOCKER 22000176 1
15 AC/DC B (15) COVERS BRACKET SIDE 29700994.C 29700994 8
