60
INSTALLATION & MAINTENANCE MANUAL • X-MIND AC • V2 • (06) • 08/2016 • NXACEN020B
ENGLISH
REF SPARE PARTS WALL PLATE 350
CODE
(RAL 9010 color)
OLD COLOR Q.TY PCS
1 PLATE (1) COVER DEG 29700985.C 29700985 5
1 PLATE (1) COVER SAT 29700986.C 29700986 5
2 AC/DC XG B & HALF-MOON LOCKER 22000176 1
3 PLATE (3) DRILL TEMPLATE 24200984 1
4
PIASTRA (4) PLASTIC JOINT + PLASTIC
CAPS
29701036.C 29701036 3
WALL PLATE 350 DEG 29700383.C 29700383 COMPLETE
WALL PLATE 350 SAT 29700384.C 29700384 COMPLETE
