②Never disassemble the encoder or motor.
③The GND of 24VDC input and the grounding cable of device can be connected to each other.
※Please use the same power supply for control voltage(24V and GND) and upper control device.
④Do not remove or maintain the encoder battery until the main power supply is switched OFF.
⑤After switching off the main power supply, please note that there is residual voltage of approx. 30 seconds on the power
components.
⑥Do not replace the fuse.
⑦The servo drives of more than 750W are installed with a cooling fan on the right side. Do not touch or block the ventilation
ports of servo drive
2.4 Dimensions of servo motor
