Action technology A3 - Page 67

67
24
-
Reserved
25
-
Reserved
26
-
Reserved
27
-
Reserved
28
-
Reserved
29
-
Reserved
30
-
Reserved
31
-
Reserved
32
A SPEED
Analog speed command input
33
A_GND
Analog speed command input ground
34
-
Reserved
35
-
Reserved
36
OUT_A
Encoder A phase output
37
/OUT_A
Encoder /A phase output
38
OUT_B
Encoder B phase output
39
/OUT_B
Encoder /B phase output
40
OUT_Z
Encoder Z phase output
41
/OUT_Z
Encoder /Z phase output
42
SG
Signal ground
43
485
EIA-485 communication data
44
/485
EIA-485 communication /data
45
SG
Signal ground
46
NC2
Reserved(Disconnected)
47
-
Reserved
48
-
Reserved
49
-
Reserved
50
-
Reserved
