10
Operation Manual
LC7-2 Wall Control
Operation Manual - LC7-2 Wall Control
Document: 0525-080 Ver. 1 190923
10.01. Fan-Only Operation
1. Press the MODE button until FAN appears on the display.
NOTE
The 1-speed or 3-speed fan option will depend on the A/C setup.
Adjust the Indoor Fan speed (LOW, MED and HIGH by pressing the FAN button successively until you reach the
desired speed (only for 3-speed fan).
10.02. Cooling Operation
1. Press the MODE button until COOL appears on the display.
2. Set the desired temperature by pressing either the or buttons.
3. Adjust the desired Indoor Fan speed by pressing the FAN button.
Available settings are: LOW, MED , HIGH, CONT LOW, CONT MED and CONT HIGH.
10.03. Heating Operation
1. Press the MODE button until HEAT appears on the display.
2. Set the desired temperature by pressing either the or buttons.
3. Adjust the desired Indoor Fan speed by pressing the FAN button.
Available settings are: LOW, MED, HIGH, CONT LOW, CONT MED and CONT HIGH.
NOTE
Setting the indoor fan speed to continuous mode can cause cool drafts when operating the system on heating mode
during compressor off cycles.
