Operation Manual
LC7-2 Wall Control
Operation Manual - LC7-2 Wall Control
Document: 0525-080 Ver. 1 190923
3. 3 seconds after the last press of the or buttons or simply press TIMER, the display will go back to
the main screen and the On Timer countdown will start. The unit will turn On after the timer has expired.
4. To cancel the ON Timer, press the button.
12. Backlight Function
12.01. LCD Backlight Level Adjustment
1. Press and continue to hold REPEAT button.
2. Press the or buttons to adjust the backlight level as follows:
• To brighten the backlight, press the button.
• To dim the backlight, press the button.
3. Release the buttons at the desired level of LCD brightness. The lock symbol will appear for 3 seconds showing
that the backlight level is set.
12.02. Permanently Turn On LCD Backlight
NOTE
By default, the LCD Backlight is programmed to turn off 15 seconds after a button has been last pressed.
1. Press and hold the REPEAT button for 4 seconds.
2. When Lock appears, release the REPEAT button and the backlight will remain Illuminated.
3. To return to default settings, repeat steps 1 and 2.
12.03. ON/OFF Button Light
NOTE
The Wall Control status must be On before operating this procedure. By default, the
button backlight is On.
