Operation Manual
LC7-2 Wall Control
Operation Manual - LC7-2 Wall Control
Document: 0525-080 Ver. 1 190923
12.03.01. Turn On the ON/OFF Button Backlight
1. Press and hold the REPEAT button.
2. Press and release the button, along with the REPEAT button.
3. Lock symbol will appear for 3 seconds showing that the button backlight is set. backlight will
remain lit.
12.03.02. Turn Off the On/Off Button Backlight
1. Press and hold the REPEAT button.
2. Press and release the button, along with the REPEAT button.
3. Lock symbol will appear for 3 seconds showing that the button backlight is set. backlight will
turn OFF.
13. Program Menu
NOTE
The Program Menu has a 60 second inactive timeout, once expired, display will return to the home screen.
Program Menu 01 (7-Day Programmable Function), 02 (Clock) and 03 (Temperature Set back) can only be set via Wall
Control 1 (C-1). Wall Control 2 and 3 (C-2 and C-3) will skip these Menu and directly proceed at Menu 04.
13.01. 7-Day Programmable Function
13.01.01. Time clock Operation
NOTE
The 7-Day Time clock feature of the LC7-2 control allows you to set the air conditioning system to Turn-ON and
Turn-OFF at different times for each day of the week.
Each day can have 2-Programmed Events.
Each event has an On and Off time.
Ensure that the current day and time are set correctly before proceeding with programming.
To reset any scheduled time clock events, press and hold the PROG and DISP buttons for 3 seconds.
13.01.02. Example of Time clock Operation
MON TUE WED THU FRI SAT SUN
EVENT 1
ON
TIME
6:00am 6:00am 6:00am 6:00am 6:00am 7:00am 8:00am
OFF TIME 10:00am 10:00am 10:00am 10:00am 10:00am 9:00am 11:00am
EVENT 2
ON
TIME
4:00pm 4:00pm 4:00pm 4:00pm 1:00pm -:-- -:--
OFF TIME 10:00pm 10:00pm 10:00pm 10:00pm 11:00pm -:-- -:--
