17
Operation Manual
LC7-2 Wall Control
Operation Manual - LC7-2 Wall Control
Document: 0525-080 Ver. 1 190923
4. Press the PROG button to move to Event 1 Off time. Press the or buttons to adjust the time
in 15 minutes increments.
5. Press the PROG button to move to Event 2 On time. Repeat Step 4 to program Event 2 On and Off time.
NOTE
Press the EXIT button at any time if no further changes to later Days/Events are required.
6. Press the PROG button to move onto Event 1 On time of following day, TUE.
7. Repeat the above steps until you have programmed all the events you require. Otherwise, press the EXIT
button twice to exit Program Menu. TIME CLOCK display will show on the screen to indicate that it is
active.
NOTE
If a button has not been pressed after 60 seconds the control will exit the Time Clock program menu and
return to the home screen. During a power failure, the control will retain the time and Time Clock settings.
