7451A/7461A/7461P Digital Multimeter Operation Manual
6.7.2 Output Data Format
6-17
With header
Without header
In the above case, header (1) and space (2) are not output.
1 Main header of 3 characters ( ) + Sub header of 1 character ( )
2 S Space
3 Mantissa Polarity + Decimal point + 6 or 7 digits numerical value
4 Exponent E + Polarity + 2 digits numerical value
5 Block delimiter
Main header Description
DCV Measurement function DC voltage measurement (DCV)
ACV AC voltage measurement (ACV)
R2W Resistance measurement (2W)
R4W Resistance measurement (4W)
DCI DC current measurement (DCI)
ACI AC current measurement (ACI)
ADV AC voltage (AC+DC coupling) measurement (ACV(AC+DC))
ADI AC current (AC+DC coupling) measurement (ACI(AC+DC))
DOD Diode measurement (Diode)
R2L Low power resistance measurement (2W
R4L Low power resistance measurement (4W
RCT Continuity test (Cont)
FRQ Frequency measurement (Freq)
BDV DCV-Bch
TC2 Temperature measurement (TEMP-2W)C
TC3 Temperature measurement (TEMP-3W)C
TC4 Temperature measurement (TEMP-4W)C
TF2 Temperature measurement (TEMP-2W)F
TF3 Temperature measurement (TEMP-3W)F
TF4 Temperature measurement (TEMP-4W)F
TK2 Temperature measurement (TEMP-2W)K
TK3 Temperature measurement (TEMP-3W)K
TK4 Temperature measurement (TEMP-4W)K
1
2
3
4
S DD...DD EDD , S DD...DD EDD , ...
6
1
2
3
4
6
5
