7451A/7461A/7461P Digital Multimeter Operation Manual
5.9.6 MAX/MIN Calculation
5-42
5.9.6 MAX/MIN Calculation
1. Function
1. This function calculates the maximum, minimum, and average values while the
MAX/MIN calculation is performed.
2. The following calculations are performed at the same time in the MAX/MIN cal-
culation.
• Maximum value (MAX)
• Minimum value (MIN)
• Average value (AVE)
• Measurement count
3. All measurement data except for overload (OL) and calculation error data can be
used for the calculation.
4. If BEEP is set to ON, the buzzer sounds when the MAX or MIN value is renewed.
However, although the displayed value is not changed, the buzzer may sound.
This is because the resolution of measurement value is higher than the resolution
of the displayed value.
2. Setting the calculation
The operation is selected as shown in below by selecting MX/MN in .
OFF: Canceling the calculation [The MAX and MIN lamps turn off.]
ON: Performing the calculation (Measurement value display) [The MAX and MIN lamps turn on.]
MAX: Performing the calculation (Maximum value display) [The MAX lamp blinks.]
MIN: Performing the calculation (Minimum value display) [The MIN lamp blinks.]
MENU
..3.. CALC
MX/MN
OFF/ON/MAX/MIN
To Next Page
