5.3 Measurement Range and Auto-Range
5-11
5.3 Measurement Range and Auto-Range
5.3.1 Measurement Function and Range Structure
Table 5-2 shows the range structure corresponding to the measurement function.
Table 5-2 Measurement Function and Range Structure
DCV DCV Bch
ACV
ACV
(AC+DC)
2W/
4W
LP-2W/
4W
DCI
ACI
ACI
(AC+DC)
FREQ Continuity Diode
7461A/61P 100 mV 100 mV 100  100  1000 A 1000 A100 mV
1000 mV 1000 mV 1000  1000  10 mA 10 mA 1000 mV 1000  1000 mV
10 V 10 V 10 V 10 k 10 k 100 mA 100 mA 10 V
100 V 100 V 100 k 100 k 1000 mA 1000 mA 100 V
1000 V 700 V 1000 k 1000 k 3 A 3 A 700 V
10 M 10 M
100 M
7451A 300 mV 300 mV 30  3000 A 3000 A300 mV
3000 mV 3000 mV 300  300  30 mA 30 mA 3000 mV 3000 mV
30 V 10V 30 V 3000  3000  300 mA 300 mA 30 V 3000 
300 V 300 V 30 k 30 k 3000 mA 3000 mA 300 V
1000 V 700 V 300 k 300 k 700 V
3000 k 3000 k
30 M 30 M
300 M
NOTE: The range settings for each function are saved.
For the frequency function, the range is not switched in the frequency range but switched in the voltage
range.
