7451A/7461A/7461P Digital Multimeter Operation Manual
6.7.4 SCPI Command Reference
6-40
2. Calculation function command
Function description SCPI Command Parameter Query reply
NULL
Calculation setting [:SENSe]:<Function>:REFerence:STATe {ON,1|OFF,0} {1|0}
NULL constant setting
The setting is enabled when
the NULL calculation is set to
ON.
[:SENSe]:<Function>:REFerence [-9999999.E+6|0|
9999999.E+6]
(7461A/61P)
[-999999.E+6|0|
999999.E+6]
(7451A)
<real_6> (7461A/61P)
<real_5> (7451A)
Smoothing
Calculation setting :CALCulate:SMOothing {ON,1|OFF,0} {1|0}
Smoothing count setting :CALCulate:SMOothing:POINts [2|10|100] <int_3>
Scaling
Calculation setting :CALCulate:SCALing {ON,1|OFF,0} {1|0}
Constant A setting*4 :CALCulate:SCALing:A { [-9999999.E+6|0|
9999999.E+6]|
MEASurement}
(7461A/61P)
{ [-999999.E+6|0|
999999.E+6]|
MEASurement}
(7451A)
<real_6> (7461A/61P)
<real_5> (7451A)
Constant B setting*4 :CALCulate:SCALing:B
Constant C setting*4 :CALCulate:SCALing:C
MAX/MIN
MAX/MIN calculation setting :CALCulate:AVERage {ON,1|OFF,0} {1|0}
MAX value reading :CALCulate:AVERage:MAXimum? Refer to Section 6.7.2,
“Output Data Format.”
MIN value reading :CALCulate:AVERage:MINimum?
AVE value reading :CALCulate:AVERage:AVERage?
Measurement count reading :CALCulate:AVERage:COUNt? <real_6> (7461A/61P)
<real_5> (7451A)
Comparator calculation
Calculation setting :CALCulate:LIMit {ON,1|OFF,0} {1|0}
High constant setting*4 :CALCulate:LIMit:UPPer { [-9999999.E+6|0|
9999999.E+6]|
MEASurement}
(7461A/61P)
{ [-999999.E+6|0|
999999.E+6]|
MEASurement}
(7451A)
<real_6> (7461A/61P)
<real_5> (7451A)
LOW constant setting*4 :CALCulate:LIMit:LOWer
Whether to set the calculation
result LOW to PASS.
:CALCulate:LIMit:PASS:LOWer {ON,1|OFF,0} {1|0}
Whether to set the calculation
result GO to PASS.
:CALCulate:LIMit:PASS:MED {ON,1|OFF,0} {1|0}
*4: How to set the parameter can be selected from entering the value directly and substituting the measurement value.
