4.5.3 Function 3: Display and adjust damp time
the stability time. An adjustment will may improve unstable performance.
(Damp time unit: second).
As figure 4-5-3-1, switch to HART function 3 by pressing .
b As figure 4-5-3-2, press to show the transmitter's damp time. Press to return to the figure 4-5-3-1.
Switch to function 4 by pressing .
c Press the direction keys to adjust the damp time. If the adjustment is successful, the screen displays _ _ _ _ _ _ for 2 seconds.
Otherwise, it will return to the interface as figure 4-5-3-1.
Damp time：
.
The operation method as following:
a.
"".
24V
HART
0255075100
Figure 4-5-3-1: F3 entrance interface Figure 4-5-3-2: display damp time
42
24V
HART
0255075100
second
damp
