Appendix I: Typical application of ADT672

The operation steps are:

① Connect the pressure gauge and

on the pressure pump.

② According to verification regulation,

make as a reference

gauge to verify (calibrate) the

pressure gauge.

(1) Pressure gauge calibration

ADT672

Main Page
