EX. In drive 01 write 2EE0H(12000rpm) to parameter address
04, but CD04 upper limit is 9999rpm (270FH).
1.RTU
Computer command message :
Drive response message :
2.ASCII
D1
01H
D2
86H
D3
02H
D4
CRCL(C3H)
D5
CRCH(A1H)
56
D1
01H
D2
06H
D3
00H
D4
04H
D5
2EH
D6
E0H
D7
CRCL
D8
CRCH
Computer command message Drive response message
STX 3A STX 3A
Address '0'
Address '1'
30
Address '0'
Address '1'
30
31 31
Function '0'
Function '6'
30
Function '8'
Function '6'
38
36 36
Address content '0'
Address content '0'
Address content '0'
Address content '4'
30
Error code '0'
Error code '2'
30
30 32
30
LRC HI '7'
LRC LO '7'
37
34 37
CD04 content '2'
CD04 content 'E'
CD04 content 'E'
CD04 content '0'
31 END HI 0D
45 END LO 0A
35
30
LRC HI LRC HI
LRC LO LRC LO
END HI 0D
END LO 0A
