ADRF ADXV-HPR - Aai; Figure 3-2 ADXV-H-NMS Front View; Figure 3-3 NMS LED; Leds

Advanced RF Technologies, Inc.
22
Figure 3-2 ADXV-H-NMS Front View
3.1.1.1 LEDs
NMS has LEDs on the front panel as shown in Figure 3-3.
Figure 3-3 NMS LED
Table 3-1 NMS LED Specifications
ADXV-HPR-NMS Specifications
POWER
Solid Green
NMS power is ON
OFF
NMS power is OFF
LINK
Solid Red
HE Link Fail alarm exists in the system
Solid Green
No HE Link Fail alarms are present in the system
3.1.1.2 AAI
AAI
SERVICE
HOST
ADXV-H-NMS-DC
LAN1
LAN0
LAN0
RTN
-48V
DC IN
REMOTE
01
02
03
04
05
P(+)
LINK
N(-)
LINKPOWER
