User Manual of TV5600-B01 Series Dispensing Control System

106

2. Output port wiring instructions

2.01 Common output ports

OUTPUT

Function

+24V

Internal 24V power supply

Universal output signal 0

+24V

Internal 24V power supply

Universal output signal 1

+24V

Internal 24V power supply

Universal output signal 2

+24V

Internal 24V power supply

Universal output signal 3

+24V

Internal 24V power supply

Universal output signal 4

EXT_24V

CON12

OUT 0

OUT 1

OUT 2

OUT 3

OUT 4

OUT 5
