8 Meadowbank Road, Carrickfergus, BT38 8YF, Northern Ireland www.advancedsensors.co.uk
Page 60 of 93
OIW-HBO-0002-EX-005
OIW EX SERIES-SIDE STREAM
OPERATION MANUAL
Rev. 004 MAY 2015
3.2.3.2.4 – Next Spectra
The ‘Line # Next Spectra’ displays the user defined spectroscopy reading period which takes place at the start of the
cycle. A spectroscopy file is created for each reading and saved in the Spec_Log files.
3.2.3.2.5 – Averaging
The ‘Averaging’ value displays the average measurement readings for a selected time. To configure the averaging time
see Section 3.2.3.1.1.2 – Water Line Options p.39.
3.2.3.2.6 – Serial Number, Software Version, Corporate Logo, Asset Tag and Start/Stop Button
A variety of system information is displayed under label 6 in Figure 74. The first number is the serial number of the unit
and will always take the form SNXXXXX. Below this is the current version of OIW software running on the analyzer and
recorded in all data logs. The serial number and software version are factory set and recorded in the build record.
The Advanced Sensors logo, when clicked, will display for 5 seconds a code required to grant temporary access. To
obtain temporary access this code, along with the unit serial number, are required by Advanced Sensors Service
Personnel. Please contact Advanced Sensors should troubleshoot or assistance required.
Any asset tag number, or other identifier, assigned to the unit can be entered and will display below the Advanced
Sensors corporate logo. A tag number up to 10 characters in length can be entered. See Section 3.2.3.1.1.1 - System
Settings p.36 to edit this display.
At the bottom of this area is the Start & Stop button. When idle, or stopped, the button will be green and read Start.
Once the button has been pressed to start the measurement cycle it will change to red and read Stop. This is accessible
to all users and does not require login access.
