99 ADAM-4000 Series User Manual
Chapter 4 Command Set
Table 4.12: ADAM-4018+ Input range and external calibrating input
source for each input type
Range
bcode(Hex)
Input Range Max. Signal Min Signal
Displayed
Resolution
06 +/-20 mA +20.000 -20.000 1uA
07 4~20 mA +20.000 +4.000 1uA
14
Type J
Thermocouple
15
Type K
Thermocouple
16
Type T
Thermocouple
17
Type E
Thermocouple
18
Type R
Thermocouple
19
Type S
Thermocouple
20
Type B
Thermocouple
Table 4.13: ADAM-4018M Command Table
Command Syntax Command Name Command Description Page No.
%AANNTTCCFF Configuration
Sets the address, input range, baud
rate, data format, checksum status,
and/or integration time for a specified
analog input module
5-4
$AA2 Configuration Status
Return the configuration parameters
for the specified analog input module
5-10
$AAF Read Version
Return the firmware version code
from the specified analog input mod-
ule
5-12
$AAM Read Module Name
Return the module name from the
specified analog input module
5-13
#AAN
Read Analog Input
from Channel N
Return the input value from channels
number N of the specified analog
input module
5-16
$AA5VV
Enable/Disable
Channels for Multi-
plexing
Enable or disable the individual chan-
nels in an analog module
5-17
$AA6 Read Channel Status
Get the enable/disable status of all
channels in an analog module
5-18
$AA0 Span Calibration
Calibrates an analog input module to
correct for gain errors
5-19
$AA1 Offset Calibration
Calibrates an analog input module to
correct for offset errors
5-20
$AA3 CJC Status
Returns the value of the CJC sensor
for a specified analog input module
5-25
$AA9SNNNN
CJC Offset
Calibration
Calibrates the CJC sensor for offset
errors
5-26
