ADAM-4000 Series User Manual 102
Table 4.15: ADAM-4021 Command Table
Command Syntax Command Name Command Description Page No.
%AANNTTCCFF Configuration
Set the address, output range, baud
rate, data format, slew rate and/or
checksum status
6-3
#AA(data) Analog Data Out
Directs output data to a specified
module
6-6
$AA4
Start-up output cur-
rent/voltage configu-
ration
Stores a default output value in a
specified module. The output value
will take effect upon startup.
6-8
$AA3(number of
counts)
Trim Calibration
Trims specified module a number of
units up/down
6-9
$AA0 4 mA Calibration
Tells the module to store parameters
for 4 mA Calibration
6-11
$AA1 20 mA Calibration
Tells the module to store parameters
for 20 mA Calibration
6-12
$AA2 Configuration Status
Reads configuration of specified
module
6-13
$AA6 Last Value Readback
Returns either last value sent to spec-
ified module by #AA command, or
start-up output current/voltage
6-14
$AA8 Current Readback
Returns measured value of the cur-
rent/voltage flowing through current
loop
6-15
$AA5 Reset Status
Checks if module has been reset
since the last $AA5 command
6-16
$AAF
Read Firmware Ver-
sion
Return the firmware version code
from the specified analog output
module
6-17
$AAM Read Module Name
Return the module name from the
specified analog output module
6-18
