287 ADAM-4000 Series User Manual
Appendix A Technical Specifications
A.4 ADAM-4013 RTD Input Module
Table A.6: ADAM-4013 Specifications
RTD channel number 1
Input type Pt or Ni RTD
Output
speed (in bps)
Maximum distance
RS-485 (2-Wire)
1200, 2400, 4800, 9600, 19.2K, 38.4K, 57.6K, 115.2K
4000 ft. (1200 m.)
Accuracy ±0.1% or better
Zero drift ±3V/°C
Span drift ±25 ppm/°C
Input connections 2, 3 or 4 wires
Isolation-rated voltage
3000 V
DC
CMR @ 50/60 Hz 150 dB
NMR @ 50/60 Hz 100 dB
Sampling rate 10 samples/second
Input impedance 2 M
Support protocol ADAM ASCII
Watchdog timer 1.6 second (System)
Power supply
+10 to +30 V
DC
(non-regulated)
Power consumption
0.7 W @ 24 V
DC
