225 ADAM-4000 Series User Manual
Chapter 7 I/O, Relay & Counter
Frequency
4080D
7.2.1.10 $AA9(data)
Name Send Data to LED command
Description The host computer sends data to the addressed module to
display on its LED.
Syntax $AA9(data)(cr)
$ is a delimiter character.
AA (range 00-FF) represents the 2-character hexadecimal
address that you will access to.
9 is the Send LED Data command.
(data) is a floating point numeral consisting of five digits,
and there can be a decimal point. Its maximum value is 99999.
(cr) is the terminating character, carriage return (0Dh)
Response !AA(cr) if the command is valid.
?AA(cr) if an invalid operation was entered.
There is no response if the module detects a syntax or
communication error, or even if the specified address does not exist.
! is a delimiter character which indicates a valid command.
? is a delimiter character which indicates an invalid command.
AA (range 00-FF) represents the 2-character hexadecimal
address of a counter/frequency module.
(cr) is the terminating character, carriage return (0Dh).
Example command: $0198999.9(cr)
response: !01(cr)
The command requests the host computer to send 8999.9 to
the counter/frequency module at address 01 for LED
display. This command is only valid after the command
$0182 has been issued.
