329 ADAM-4000 Series User Manual
Appendix B Data Formats and I
/
O Ranges
Range Code
(hex)
Input Range
Description
Data Formats +F.S. Zero -F.S.
Displayed
Resolution
09 ± 5 V
Engineering
Units
+5.0000 ±0.0000 -5.0000 1 LSB*
% of FSR +100.00 ±000.00 -100.00 100.00 µv
Twos
Complement
7FFF 0000 8000 0.01%
0A ± 1 V
Engineering
Units
+1.0000 ±0.0000 -1.000 1 LSB*
% of FSR +100.00 ±000.00 -100.00 100.00 µv
Twos
Complement
7FFF 0000 8000 0.01%
0B ± 500 mV
Engineering
Units
+500.00 ±000.00 -500.00 1 LSB*
% of FSR +100.00 ±000.00 -100.00 10 µv
Twos
Complement
7FFF 0000 8000 0.01%
0C ± 150 mV
Engineering
Units
+150.00 ±000.00 -150.00 1 LSB*
% of FSR +100.00 ±000.00 -100.00 10 µv
Twos
Complement
7FFF 0000 8000 0.01%
0D ± 20 mV
Engineering
Units
+20.000 ±00.000 -20.000 1 LSB*
% of FSR +100.00 ±000.00 -100.00 1 µv
Twos
Complement
7FFF 0000 8000 0.01%
