365 ADAM-4000 Series User Manual
Appendix G I/O Modbus Mapping Table
5. ADAM-4024 4-channel Analog Output Module
ADDR 0X Channel Item Attribute Memo
00001 0 Emergency DI Input Flag R
00002 1 Burn-out Signal R
00003 2 Burn-out Signal R
00004 3 Burn-out Signal R
ADDR 4X Channel Item Attribute Memo
40001 0 Current Output Value R/W
40002 1 Current Output Value R/W
40003 2 Current Output Value R/W
40004 3 Current Output Value R/W
40201 0 Type Code R/W
40202 1 Type Code R/W
40203 2 Type Code R/W
40204 3 Type Code R/W
40211 Module Name 1 R 0x40 0x24
40212 Module Name 2 R 0x00 0x00
40213 Version
1
R 0xa2 0x00
40214 Version
2
R 0x00 0x00
40215 Comm Safety Enable R Enable:0x00 0x01
40216 Comm Safety Flag R Occur:0x00 0x01
40221 Channel Enable R/W 0x00 0xff
