367 ADAM-4000 Series User Manual
Appendix G I/O Modbus Mapping Table
7. ADAM-4055 16-channel Isolated Digital I/O with LED Module
ADDR 0X Channel Item Attribute Memo
00001 0 DI Input Signal R
00002 1 DI Input Signal R
00003 2 DI Input Signal R
00004 3 DI Input Signal R
00005 4 DI Input Signal R
00006 5 DI Input Signal R
00007 6 DI Input Signal R
00008 7 DI Input Signal R
00017 0 DO Output Value R/W
00018 1 DO Output Value R/W
00019 2 DO Output Value R/W
00020 3 DO Output Value R/W
00021 4 DO Output Value R/W
00022 5 DO Output Value R/W
00023 6 DO Output Value R/W
00024 7 DO Output Value R/W
ADDR 4X Channel Item Attribute Memo
40211 Module Name 1 R 0x40 0x55
40212 Module Name 2 R 0x00 0x00
40213 Version 1 R 0xa2 0x00
40214 Version 2 R 0x00 0x00
40215 Comm Safety Enable R
Enable:0x00
0x01
40216 Comm Safety Flag R
Occur:0x00
0x01
