371 ADAM-4000 Series User Manual
Appendix G I/O Modbus Mapping Table
11. ADAM-4069 8 Power Relay Output Module
12. ADAM-4080 2-ch Counter/Frequency Module
ADDR 0X Channel Item Attribute Memo
00017 0 Relay Output Value R/W
00018 1 Relay Output Value R/W
00019 2 Relay Output Value R/W
00020 3 Relay Output Value R/W
00021 4 Relay Output Value R/W
00022 5 Relay Output Value R/W
00023 6 Relay Output Value R/W
00024 7 Relay Output Value R/W
ADDR 4X Channel Item Attribute Memo
40211 Module Name 1 R 0x40 0x69
40212 Module Name 2 R 0x00 0x00
40213 Version 1 R 0xa1 0x01
40214 Version 2 R 0x00 0x00
40215 Comm Safety Enable R Enable:0x00 0x01
40216 Comm Safety Flag R Occur:0x00 0x01
ADDR 0X Channel Item Attribute Memo
00017 0
DO0 Signal/Counter 0
Alarm Status
R/W Alarm is read only
00018 1
DO1 Signal/Counter1
Alarm Status
R/W Alarm is read only
00033 Counter0 Start/Stop R/W
1: start
0: stop
00034 Counter0 Clear W 1: clear counter
00035 Counter0 Overflow R
00037 Counter1 Start/Stop R/W
1: start
0: stop
00038 Counter1 Clear W 1: clear counter
00039 Counter1 Overflow R
ADDR 4X Channel Item Attribute Memo
40001-
40002
0 Counter 0 Value R
40003-
40004
1 Counter 1 Value R
40201 Counter Mode R
50:Counter
51:Frequency
40202 Signal Input Mode R
0: non-isolated (TTL)
input 1
:photo-isolated input
