Chapter 6
Planning Your Application Program mal Modbus
network address of an ADAM-5000/ TCP system.
(cr) is the terminating character, carriage return (0Dh).
Example command: %01000A40(cr)
response: !01(cr)
The ADAM-5000/TCP system with address 01h is
configured to a baud rate of 115.2 Kbps and with
checksum generation or validation.
The response indicates that the command was re-
ceived. Wait 7 seconds to let the new configuration
setting take effect before issuing a new command to
the system.
Note: All configuration parameters can be changed dynami-
cally, except checksum and baud rate parameters.
They can only be altered when the INIT* terminal is
grounded.
Baud Rate Code Baud Rate
03h 1200 bps
04h 2400 bps
05h 4800 bps
06h 9600 bps
07h 19.2 Kbps
08h 38.4 Kbps
09h 57.6 Kbps
0Ah 115.2 Kbps
Table 6-3 Baud rate codes
6-42 ADAM-5000/TCP User’s Manual
