This manual introduces the detail specifications functions and
application wiring of each ADAM-5000 I/O modules.To organize an
ADAM-5000 series and ADAM-5510 Series Controller, you need to select
I/O modules to interface the main unit with field devices or processes that
you have previously determined. Advantech provides 20 types of ADAM-
5000 I/O modules for various applications so far. Following table is the I/ O
modules support list we provided for user’s choice. More detailed
specification and user’s guides, please refer the user’s manual of
ADAM-5000 IO Module
. It had integrated and collected this information.
Module Name Specification Reference
ADAM-5013 3-ch. RTD input Isolated
ADAM-5017 8-ch. AI Isolated
ADAM-5017H 8-ch. High speed AI Isolated
ADAM-5017UH 8-ch. Ultra High speed AI Isolated
ADAM-5018 7-ch. Thermocouple input Isolated
Analog I/O
ADAM-5024
4-ch. AO Isolated
ADAM-5050 7-ch. D I/O Non-isolated
ADAM-5051 16-ch. DI Non-isolated
ADAM-5051D 16-ch. DI W/ LED Non-isolated
ADAM-5052 8-ch. DI Isolated
ADAM-5056 16-ch. DO Non-isolated
Digital I/O
ADAM-5056D
16-ch. DO W/LED Non-isolated
ADAM-5060 6-ch. Relay output Isolated Relay Output
ADAM-5068
8-ch. Relay output Isolated
Counter/Frequenc
ADAM-5080 4-ch. Counter/Frequency Isolated
Serial I/O ADAM-5090 4-port RS232 Non-isolated
Table 4-1 I/O Module Support List
ADAM-5000
4-
2
