Chapter 5
System Hardware Configuration
5-3-3 Add Remote Station
To meet the remote monitoring and maintenance requirements, ADAM-
5000/TCP Series System does not only available to operate in local
LAN, but also allowed to access from internet or intranet. Thus users
would able to configure an ADAM-5000/TCP Series easily no matter
how far it is. Select item T
ool\Add 5000/TCP in function menu or click the
button, the adding station screen will pop up as Figure 5-8.
Then key-in the specific IP address and click the A
dd button. If the
communication suc- cess, the added ADAM-5000/TCP Series unit
should appeal on the tree-struc- ture display area.
Figure 5-8: Adding ADAM-5000/TCP screen
Note: There are several conditions need to be sure before adding a
remote ADAM-5000/TCP Series system in the windows Utility.
1. Be sure the specific IP is existed and available.
2. Be sure to complete the network linkage for both sides.
3. Be sure to adjust the best timing of timeout setting.
4. Even you are not sure whether the communication is
work- able or not, there is also a “PING” function for
testing the network connection.
5-8 ADAM-5000/TCP User’s Manual
