Advantech ADAM-5000L/TCP User Manual

Appendix A
Design Worksheets
An organized system configuration will lead to efficient performance and
reduce engineer effort. This Appendix provides the necessary worksheet,
helping users to configure their DA&C system in order. Follow these
working steps to build up your system relational document:
Step 1: Asking questions and getting answers for your control
strat- egy.
1) What will be monitored and controlled? (List the equipment)
2) What will be monitored and controlled separately? (Divide the func-
tion area)
3) What will be monitored and controlled by ADAM-5000/TCP? (List
the target equipment in different function areas)
Step 2: Identify the I/O types of each equipment and full-fill Table A-1
to establish the I/O data base.
A-2 ADAM-5000/TCP User’s Manual

Advantech ADAM-5000L/TCP Specifications

General

Brand	Advantech
Model	ADAM-5000L/TCP
Category	I/O Systems
Language	English
