Advantech ADAM-5000L/TCP User Manual

Module
Range
Code
Input Range
Description
Data
Formats
Maximum
Specified
Signal
Minimum
Specified
Signal
Displayed
Resolution
Actual
Value
Engineering
Units
+760.00 +000.00 0.1°C
% of FSR +100.00 +000.00 0.01%
0Eh
Type J
Thermocouple
0°C to 760°C
Two's
Complement
7FFF 0000 1 LSB
Reading/
10
Engineering
Units
+1370.0 +0000.0 0.1°C
% of FSR +100.00 +000.00 0.01%
0Fh
Type K
Thermocouple
0°C to 1370°C
Two's
Complement
7FFF 0000 1 LSB
Reading/
10
Engineering
Units
+400.00 -100.00 0.1°C
% of FSR +100.00 -025.00 0.01%
10h
Type T
Thermocouple
-100°C to
400°C
Two's
Complement
7FFF E000 1 LSB
Reading/
10
Engineering
Units
+1000.00 +0000.0 0.1°C
% of FSR +100.00 ±000.00 0.01%
11h
Type E
Thermocouple
0°C to 1000°C
Two's
Complement
7FFF 0000 1 LSB
Reading/
10
Engineering
Units
+1750.0 +0500.0 0.1°C
% of FSR +100.00 +028.57 0.01%
12h
Type R
Thermocouple
500°C to
1750°C
Two's
Complement
7FFF 2492 1 LSB
Reading/
10
Engineering
Units
+1750.0 +0500.00 0.1°C
% of FSR +100.00 +028.57 0.01%
13h
Type S
Thermocouple
500°C to
1750°C
Two's
Complement
7FFF 2492 1 LSB
Reading/
10
Engineering
Units
+1800.0 +0500.0 0.1°C
% of FSR +100.00 +027.77 0.01%
ADAM-
5018P
14h
Type B
Thermocouple
500°C to
1800°C
Two's
Complement
7FFF 2381 1 LSB
Reading/
10
B-6 ADAM-5000/TCP User’s Manual
