Advantech ASMB-585 - External Speaker Connector (JFP2); Reset Connector (JFP1); HDD LED Connector (JFP2)

103 ASMB-585 User Manual
Appendix B I/O Pin Assignments
B.8 External Speaker Connector (JFP2)
B.9 Reset Connector (JFP1)
B.10 HDD LED Connector (JFP2)
Table B.8: External Speaker Connector (JFP2)
Pin Function
1 SPK_VCC
4 SPK_OBS
7 SPK_BUZ
10 SPK_OUT
1 4 7 10
Table B.9: Reset Connector (JFP1)
Pin Signal
9 RESET
12 GND
9
12
Table B.10: HDD LED Connector (JFP2)
Pin Signal
2 HDD_LED+
5 HDD_LED-
2
5
