2.8 System FAN Connector (SYSFAN0, SYSFAN1,
SYSFAN2 and SYSFAN3)
If a fan is used, this connector supports cooling fans that draw up to 1A (12W).
SYS
FAN0
SYSFAN_
SEL1
SYS
FAN1 & 2
SYSFAN3
