Chapter 1 Hardware Configuration
1.3 Specifications
1.3.1 System
 SATA hard disk drive interface: Seven on-board SATA III connectors support
Advanced Host Controller Interface (AHCI) technology and have data transmis-
sion rates up to 600 MB/s.
 System Chipset: Intel® C236
1.3.2 Memory
 RAM: Up to 64 GB in four 288-pin DIMM sockets. Supports dual-channel DDR4
ECC/Non-ECC 1600/1866/2133 SDRAM.
1.3.3 Input/Output
 PCIe slot: 1 x PCIe x16 expansion slots (Gen3 x16 link) and 2 PCIe x4 expan-
sion slots (Gen3 x4 link) and 1 PCIe x4 expansion slot (Gen3 x1 link)
 Serial port: Five serial ports (on board pin headers), only supports RS-232
 PS/2 Keyboard and mouse connector: To save rear I/O space, ASMB-585
reserve a 6-pins header on board (KBMS1) and via a cable kit to build two 6-pin
mini-DIN connectors for easy connection to PS/2 keyboard and mouse.
 USB port: Supports up to 6 USB 3.0 ports with transmission up to 5Gbps and 7
USB 2.0 ports with transmission rates up to 480 Mbps.
 LPC: One LPC connector to support Advantech TPM LPC modules and COM
232/485 modules.
 GPIO: ASMB-585 supports 8-bit GPIO from super I/O for general purpose con-
trol application.
1.3.4 Graphics
 Processor is integrated Intel HD Graphics.
 Display memory: 1 GB maximum shared memory with 2 GB and above system
memory installed
 DVI-D: Up to resolution 1920 x 1200 @ 60 Hz refresh rate
 D-Sub: Up to 1920 x 1200 resolution @ 60 Hz refresh rate
1.3.5 Ethernet LAN
 Supports four 10/100/1000 Mbps Ethernet port (s) via PCIe bus which provides
a 300 MB/s data transmission rate.
 Interface: 10/100/1000 Mbps
 Controller: LAN1: Intel I219-LM; LAN2 ~ 4: Intel I210-AT (G4 sku: 4 lan ports;
G2 sku: 2 lan ports).
1.3.6 Industrial Features
 Watchdog timer: It can generate system reset or NC. The watchdog timer is
programmable, with each unit equal to one second (255 levels).
Note! 1. Due to the inherent limitations of PC architecture, the system may not
fully detect 64 GB RAM when 64 GB RAM is installed.
2. A 32-bit OS may not fully detect 4 GB of RAM when 4 GB is installed.
