31
ASMB-585 User Manual
Chapter 2
Connecting
Peripherals
2.18
Low Pin Count Connector (LPC1)
LPC connector on AIMB-584 is
reserved for Advantech LPC and COM 232/485
modules.
T
able 2.3: Advant
ech LPC Module List
Advantech P/N
Description
PCA-TPM-00A1E
TPM Module
PCA-COM232-00A1E
4 ports RS-2
32 module connect to LPC connector
PCA-COM485-00A1E
4 ports RS-485 module co
nnect to LPC connector
LP
C1
42
44
