ASMB-585 User Manual 4
1.3.7 Mechanical and Environmental Specifications
 Operating temperature: 0 ~ 60° C (32 ~ 140° F, Depending on CPU)
 Storage temperature: -40 ~ 85° C (-40 ~ 185° F)
 Humidity: 5 ~ 95% non-condensing
 Power supply voltage: +3.3 V, +5 V, ±12 V, 5 VSB
 Power consumption:
Max. load: +3.3 V @ 17.57 A, +5 V @ 20.5 A, +12 V @ 40.01 A, +5 VSB @ 2 A,
-12 V @ 0.5 A
 Board size: 228.6 x 228.6 mm (9.6" x 9.6")
 Board weight: 0.5 kg (1.68 lb)
1.4 Jumpers and Connectors
Connectors on the ASMB-585 motherboard link it to external devices such as hard
disk drives and a keyboard. In addition, the board has a number of jumpers that are
used to configure your system for your application.
The tables below list the function of each of the jumpers and connectors. Later sec-
tions in this chapter give instructions on setting jumpers. Chapter 2 gives instructions
for connecting external devices to your motherboard.
Table 1.1: Jumper list
Label Function
JCMOS1 CMOS clear
JME1 Intel ME Disable Jumper for ME/BIOS update
JWDT1 Watch Dog Reset
CPUFAN_SEL1,
SYSFAN_SEL1
FAN PWM(1-2)/DC mode selection(2-3)
PSON1 AT(1-2) / ATX(2-3)
JCASE1 Case Open
JPEG1, JPEG2
PCIEX16_SLOT6 PCIe Link switch between x16 or x8x8
or x8x4x4
JTHR_SEL1 To select on board or external thermometer
JGREEN1 Enable/Disable deep sleep mode
JUSB1
Rear window USB2.0/3.0 port power source switch
between +5 VSB and +5 V
JUSB2
On board USB2.0/3.0 port power source switch between
+5 VSB and +5 V
