ASMB-585 User Manual 28
2.15 PCIe x4 Expansion Slot (PCIEX4_SLOT4/5/7)
PCIEX4_SLOT4 is Gen3 x4 link.
PCIEX4_SLOT5 is Gen3 x1 link.
PCIEX4_SLOT7 is Gen3 x4 link.
PCIEX4_SLOT4
PCIEX4_SLOT5
PCIEX4_SLOT7
