Advantech DS-370 User Manual

3 DS-370 User Manual
Chapter 1 General Introduction
1.3 Hardware Specifications
 CPU: Intel® Celeron® J1900 quad-core, 2.0 GHz processor
 System Chipset: SoC solution with built-in Intel® Celeron® J1900 processor
 BIOS: AMI uEFI 64 Mbit Flash BIOS
 System Memory: 2 x DDR3L SO-DIMM sockets support up to 8 GB of DDR3L
1333 MHz memory (Max. 4 GB per SO-DIMM socket)
 Processor Graphics: Intel® HD Graphics
 HDD: Supports 1 x 2.5" (7 mm height) SATA HDD
 SSD: 64 GB MLC micro SSD on-board storage (optional) or shared 2.5" (7 mm
height) SATA HDD drive bay
 Watchdog Timer: Supported by Advantech SUSIAccess API
 I/O Interface: 2 x RS-232
 USB: 1 x USB 3.0 and 3 x USB 2.0 ports
 Audio: Supports 1 x mic-in and 1 x SPDIF/line-out port
 Ethernet Chipset: 2 x Intel 211 (Gigabit LAN)
– Speed: 10/100/1000 Mbps
– Interface: 2 x RJ-45 jacks with LED
– Standard: IEEE 802.3z/ab (1000 Base-T) or IEEE 802.3u 100 Base-T compli-
ant
 Expansion
– Mini PCIe: 2 internal sockets (full size)
 Resolution
– HDMI: Up to 1920 x 1080 @60 Hz
– DP++: Up to 1920 x 1080 @60 Hz
– VGA : Up to 2048 x 1280 @60 Hz
Note! 1. The mini PCIe socket on the bottom supports an mSATA interface
(This function is disabled if users choose the on-board micro SSD
option.)
2. The SIM socket only functions with the mini PCIe module on the
same side, and does not work with the mini PCIe socket on the bot-
tom.
