Chapter 1 Overview
1.3 Packing List
Please refer to below packing list:
 UNO-2271G V2
 1 x plug-in block for power wiring
 Simplified Chinese manual
 Quick Start Guide
 Warranty card
If anything is missing or damaged, contact your distributor or sales representative
immediately.
1.4 Hardware Specifications
1.4.1 General
1.4.2 System Hardware
1.4.3 I/O Interfaces
Dimensions (W x D x H) 30 x 70 x 100 mm (11.8 x 27.6 x39.3 in)
Weight (Net) 0.5 kg (1.1 lbs)
Mounting Stand/Wall mount (Optional Din-rail mount/VESA mount)
Power Requirement
10 - 30V
DC
Power Consumption
16W (typical), 30W (Max)
with 2nd stack expansion module (UNO-2271G-RP1EA):
Max to 33.3W (PoE input Max to 25.5W)
with 2nd stack expansion module (UNO-2271G-RS2EA):
Max to 34.8W
BIOS AMI EFI X64
Watchdog Timer Programmable 255 levels timer interval, from 1 to 255 sec
Hardware Security TPM 2.0
Processor
Intel Celeron
®
N6210 1.2GHz or Pentium
®
N6415 1.2GHz
Memory Onboard 4GB DDR4 1600MHz (Up to 8GB)
Graphics Engine
Intel
®
HD Graphics
Ethernet
Intel
®
Ethernet Controller i211AT/i210AT, IEEE1588
LED Indicators 1x RUN (programmable),1 x Power, and LAN (active, status)
Storage
Onboard 32GB eMMC (upgradeable, up to 256GB)
Option mSATA shared with mPCIe slot
Expansion 1 x Full size mPCIe slot (SATA/PCIe/USB2.0 signal)
LAN Ports
2 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000BASE-T Fast
Ethernet
USB Ports 2 x USB 3.2 GEN1
Displays 1 x HDMI (1920 x 1080 @60Hz)
Power Connector 1 x 2 pin terminal block
