Advantech UNO-2271G V2 User Manual

UNO-2271G_V2 User Manual 4
1.4.4 Environment
1.4.5 Certification
1.4.6 Extension Kit (Optional)
UNO-2271G V2 features a modularized design. Advantech offers two optional 2nd
stack extension kits for users to expand the functionality using an Advantech iDoor
module.
Operating Temperature* -20 ~ 60° C (-4 ~ 140° F) @5~85% RH with 0.7 m/s airflow
Storage Temperature -40 ~ 85° C (-40 ~ 185° F)
Relative Humidity 10~95% RH @ 40° C/104° F, non-condensing
Shock Protection Operating, IEC 60068-2-27, 50G, half sine, 11ms
Vibration Protection
Operating, IEC 60068-2-64, 2Grms, random, 5 ~500Hz, 1hr/
axis (mSATA)
Ingress Protection IP30
Certification CE, FCC, UL, CCC, BSMI
Part number UNO-2271G-RP1EA
Description 2nd stack extension kit to support POE PD, COM, M.2 B key
Ports 1 x POE (802.3AT), 1 x COM
Dimensions (W x D x H) 30 x 70 x 100 mm (11.8 x 27.6 x39.3 in)
Weight 0.3 kg (0.66 lbs)
Note! Due to max 25.5W supply via POE, USB ports should be limited to con-
nect with USB2.0 devices only.
Part number UNO-2271G-RS2EA
Description 2nd stack extension kit to support COM, M.2 B key, M.2 E key
Ports 2 x COM, 1 x M.2 B key, 1 x M.2 E key
Dimensions (W x D x H) 30 x 70 x 100 mm (11.8 x 27.6 x39.3 in)
Weight 0.2 kg (0.44 lbs)
Part number UNO-2271G-EKCE
Description
2nd stack extension kit to support 1 x iDoor module w/ powder
coat
Ports 1 x iDoor installation space
Dimensions (W x D x H) 30 x 70 x 100 mm (11.8 x 27.6 x39.3 in)
Weight 0.1 kg (0.22 lbs)
Note! Most of the iDoor modules can handle system operating temperatures of
60° C (140° F). (Exception: PoE iDoor, USB 3.0 iDoor).
