COM56 Serial port pin header
MPCIE1 MiniPCIe Connector
MPCIE2 MiniPCIe Connector
NVME1 M.2 M key for 2280 Connector
M2_B1 M.2 B key for 2242/3052 Connector
GPIO1 GPIO interface
SIM1 Nano SIM slot for M2_B1
PSON1 AT/ ATX setting
Table 2.1: Connectors and Jumpers
