WISE-4000 User Manual 108
40231~40232 0
Physical
AI Floating Value
(IEEE754)
Read
40233~40234 1 Read
40235~40236 2 Read
40237~40238 3 Read
40239~40240
Average
Channel 0~3
Read
40201 0
AI Type Code**
(The type codes of chan-
nels for average value
can't be changed.)
R/W
40202 1 R/W
40203 2 R/W
40204 3 R/W
40205
Average
Channel 0~3
R
* AI Status (2 Registers)
Lower Register Higher Register
Bit Description Bit Description
0 Fail to Provide AI Value 0 DI triggered to Safety Value
1 Over Range 1 DI triggered to Startup Value
2 Under Range 2 Reserved
3 Open Circuit / Burnout 3 Reserved
4 Reserved 4 Reserved
5 Unavailable Channel Configuration 5 Reserved
6 Reserved 6 Reserved
7 ADC Initializing/Error 7 Reserved
8 Reserved 8 Reserved
9 Zero/Span Calibration Error 9 Reserved
10 Reserved 10 Reserved
11 Reserved 11 Reserved
12 Reserved 12 Reserved
13 Reserved 13 Reserved
14 Reserved 14 Reserved
15 Reserved 15 Reserved
