Page #117 background image
109 WISE-4000 User Manual
Appendix A I/O Modbus Mapping Table
** AI Type Code (2 Registers)
Input Type Input Range Type Code
Unipolar
Voltage
0~10 V 0x0148
0~5 V 0x0147
0~1 V 0x0145
0~500m V 0x0106
0~150m V 0x0105
Bipolar
Voltage
+/-10V 0x0143
+/-5V 0x0142
+/-1V 0x0140
+/-500mV 0x0104
+/-150mV 0x0103
Current
0~20mA 0x0182
4~20mA 0x0180
+/-20mA 0x0181
DI Mode DI 0x01E0
