UPS IST7 (10KVA-40KVA)
User Manual 2 Overview
7
Illustration for touch screen operation panel
No. Name Illustration
Illustration for operation panel
Touch screen display Shows the working status and system setting.
AC/DC indicator
On (green): rectifier works normally;
On (red): rectifier abnormal.
DC/AC indicator
On (green): inverter works normally;
On (red): inverter abnormal.
BYP. indicator
On (green): bypass output;
On (red): bypass abnormal.
BATT. LOW indicator On (red): battery is low-voltage.
OVERLOAD indicator On (red): output is overload or overload protection.
Buttons operation instructions
"BATT. Start" button
Press "BATT. Start" button for 7s, the system will build the
aux power.
"ON" combination button
Press a couple "ON" buttons for 1s at the same time, the
system will power on.
"OFF" combination
button
Press a couple "OFF" buttons for 1s at the same time, the
system will power off.
EPO emergency power
off button
Press the button, the system will power outage
immediately.
