UPS IST7 (10KVA-40KVA)
User Manual 3 Installation
25
31 mode
10kVA 15KVA 20KVA 30KVA 40KVA
Grounding wire (PE) 2*10 2*10 2*10 25 25
Recommended cross-sectional area of wire (unit: mm
2
, environment temperature: 25℃)
11 mode
10KVA 15KVA 20-40KVA
Mains input live wire (L) 16 25 25
Input neutral wire (N) 16 25 25
Bypass input live wire (L) 16 25 25
Mains output live wire (L) 16 25 25
Mains output neutral wire
(N)
16 25 25
DC input (+/BATN/-) 10 10 10
Grounding wire (PE) 2*10 2*10 2*10
3.3 Transport and Unpacking
3.3.1 Transport
The UPS can be transported by forklift and manual forklift. When lifting the device, the
device’s center of gravity should be at the centre of the forklift arm. Keep the devices moving
slowly and stably.
3.3.2 Unpacking
Determine the unpacking site in advance. In principle, the unpacking site should be as close as possible
to the installation site.
Check if the package appearance is in good condition and if there is any damage caused by transportation.
If damaged, please inform the carrier immediately.
