3 Installation
UPS IST7 (10KVA-40KVA)
User Manual
24
33 mode
10KVA 15KVA 20KVA 30KVA 40KVA
Mains input neutral wire
(N)
4 6 6 16 16
Bypass input neutral wire
(N)
4 6 6 16 16
Bypass input live wire
(U/V/W)
4 6 6 16 16
Mains output live wire
(U/V/W)
4 6 6 16 16
Mains output neutral wire
(N)
4 6 6 16 16
DC input (+/BATN/-) 10 10 10 2*10 2*10
Grounding wire (PE) 4 6 6 16 16
Recommended cross-sectional area of wire (unit: mm
2
, environment temperature: 25℃)
31 mode
10kVA 15KVA 20KVA 30KVA 40KVA
Mains input live wire
(U/V/W)
4 6 6 16 16
Input neutral wire (N) 16 25 25 2*25 2*25
Bypass input live wire (L) 16 25 25 2*25 2*25
Mains output live wire (L) 16 25 25 2*25 2*25
Mains output neutral wire
(N)
16 25 25 2*25 2*25
DC input (+/BATN/-) 10 10 10 2*10 2*10
