AEC UPS IST7 - Installation Procedures; Installation Announcements and Preparation

2 Overview
UPS IST7 (10KVA-40KVA)
User Manual
16
Fittings illustration
Name Illustration Sketch map
Short circuit wire of
mains-and-bypass
The length is 200mm
10~20K extension
battery wiring assembly
(optional)
1m or 3m of the wiring length for
selection (optional)
30~40K extension
battery wiring assembly
(optional)
1m or 3m of the wiring length for
selection (optional)
1# connector jumper 2PIN connector jumper (optional)
2# connector jumper 3PIN connector jumper (optional)
3# connector jumper 2PIN connector jumper (optional)
4# connector jumper 3PIN connector jumper (optional)
