Benchmark 2.0 LN Installation, Operation & Maintenance Manual
CHAPTER 2 – INSTALLATION
OMM-0046_0J AERCO International, Inc. • 100 Oritani Dr. • Blauvelt, NY 10913 Page 17 of 168
GF-123 Ph.: 800-526-0288 06/18/2015
CAUTION
While packaged in the shipping container, the boiler must be moved by pallet
jack or forklift from the FRONT ONLY.
FOR MASSACHUSSETTS ONLY
For Massachusetts installations, the boiler must be installed by a plumber or
gas fitter who is licensed within the Commonwealth of Massachusetts. In
addition, the installation must comply with all requirements specified in
Chapter 1 (Safety Precautions).
2.4.2 Setting the Unit
The unit must be installed on a 4 inch to 6 inch housekeeping pad to ensure proper condensate
drainage (see NOTE below). If anchoring the unit, refer to the dimensional drawings in Appendix F
for anchor locations. Two lifting tabs are provided at the top of the heat exchanger. Figure 2-2
shows the location of the tab on the top-left side. The second tab is located on the top-right side of
the heat exchanger. USE THESE TWO TABS TO LIFT AND MOVE THE UNIT. Remove the top
panel from the unit to provide access to the lifting tabs. Remove the four (4) lag screws securing
the unit to the shipping skid. Lift the unit off the shipping skid and position it on the 4 inch to 6 inch
housekeeping concrete pad (required) in the desired location.
NOTE
When using the AERCO Condensate Neutralizer Tank for proper condensate
drainage, the Neutralizer Tank must be stored in a pit, OR the boiler and
AERCO Condensate Trap must be elevated higher than 4” above the floor.
See Condensate Tank instructions in TID-0074 for details.
WARNING
WHEN LIFTING OR MOVING THE BOILER:
• DO NOT MANIPULATE THE BOILER USING THE GAS TRAIN OR
BLOWER
• WHEN USING THE LIFTING TABS, ENSURE THERE IS NO LOAD
PLACED ON THE GAS TRAIN OR BLOWER
