7.6 FLAMMABLE GAS AND SOFTWARE VERSION MONITOR
1
6/9 10:25:36
I/O
23/11/21
00
23/11/21
0.0.14
0.0.19
ppm ppm
Release Date
Leak Detector
Leak Detector 2
Gas Level
Leak Detector 1
Gas Level
pGDx Software
Version
Release Date
pCO5+ Software
Version
— Control card software version and version date
— Display software version and version date
— Concentration of ammable gas detected by sensor 1
— Concentration of ammable gas detected by sensor 2
7.7 COMPRESSED STATUS MONITOR A
1
7/9 10:26:50
I/O
0
0
0.0 °C
rpm rpm
0
0.0 °C
0.0 °C
s
s
0
Min On Time
Oil Temperature
Min O Time
Speed
Gas Type
Discharge
Temperature
Speed Setpoint
Suction
Temperature
Bitzer Inverter
— Intake temperature read by the compressor
— Delivery temperature read by the compressor
— Oil temperature read by the compressor
— Type of gas set in the compressor
— Speed set from card setpoint
— No. of revs read by the compressor
— Minimum operating time remaining
— Minimum switching o time remaining
7.8 COMPRESSED STATUS MONITOR B
1
8/9 10:27:35
I/O
Warning
Starting
Alarm
Running
Enable
On Ref.
Coast
Ok
Envelope
Stopped
State
Bitzer Inverter
This mask displays:
1. Status:
— Stopped: compressor stopped
— Starting: compressor starting
— ON: compressor operating
— Switching o: compressor switching o
— War IN: out of envelope warning in warning zone
— War OUT: out of envelope warning in critical zone
— Alarm: compressor alarm
2. Envelope zone:
— Ok
— Suction Low, Discharge Low
— Suction Low
— Suction Low, Discharge High
— Discharge High
— Suction High, Discharge High
— Suction High
— Suction High, Discharge Low
— Discharge Low
3. Compressor status summary:
— Coast: emergency stop
— Enable: enabled to start
— Alarm: alarm
— Warning: Warning
— At ref.: setpoint reached
— ON: OPERATING
— Starting: starting up
7.9 VALVE STATUS MONITOR
1
9/9 10:26:50
I/O
0.0
0.0
%
0
stp
bar
0
stp
0.0
%
0.0
bar
1 12 2
EEV 2 Position
Digital Output
S2: Suction
Temperature
Digital Input
EEV 1 Position
S1: Pressure
Transducer
Electronic Valve EVD Evolution
— Valve driver pressure and temperature
— Valve driver digital inputs
— Valve driver digital outputs
— Valve 1 position
— Valve 2 position
