18 INSTALLER MENU
This menu contains the parameters necessary for the machine conguration and
its functions.
18.1 PASSWORD MONITOR TO ACCESS THE INSTALLER
MENU
Enter the password to access the menu (the password is 0000).
000
0
Installer Password
18.2 PROBE AND TRANSDUCER ENABLING MONITOR A
B1: Y B2: Y
U:1
B3: Y
B4: Y B5: Y B6: N
Probes enable
Probe and transducer presence enabling:
— B1 (P.A.)
— B2 (P.B.)
— B3 (TIA / TUAC)
— B4 (TGP)
— B5 (TUA)
— B6 (A.T.)
18.3 PROBE AND TRANSDUCER ENABLING MONITOR B
B7: N B9: Y
B8: N B10: Y
Probes enable
Probe and transducer presence enabling:
— B7 If used as the multifunction input DO NOT ENABLE
— B8 (SUWH)
— B9 (TEV)
— B10 (SIWH)
18.4 HIGH PRESSURE TRANSDUCER LIMITS MONITOR
4-20mA
00.0bar4mA
30.0bar20mA
High pressure probe
conguration
Full scale limits for high pressure transducer 4-20mA.
18.5 LOW PRESSURE TRANSDUCER LIMITS MONITOR
4-20mA
00.0bar4mA
10.0bar20mA
Low pressure probe
conguration
Full scale limits for low pressure transducer 4-20mA.
18.6 DIGITAL INPUT COMMAND ENABLING MONITOR
N
N
Digital input remote
on/o
Digital input remote
Cooling/Heating
— Digital input ON/OFF command enabling (MASTER ONLY).
— Digital input cooling/heating command enabling
18.7 SUPERVISOR COMMAND ENABLING MONITOR
N
N
Enable on/o by
supervisor
Enable cool/heat by
supervisor
